型號/Mode

規(guī)格/Specifications

銅絲根數(shù)/標稱直徑
Number/nominal diameter of copper wire

成品外徑OD
Outer Diameter OD of Finished Products

電纜重量km/kg
Cable weight km/kg

UL 1007

30AWG

7/0.1

1.05

1.5

UL 1007

28AWG

7/0.127

1.2

2.2

UL 1007

26AWG

7/0.16

1.31

2.9

UL 1007

24AWG

11/0.16

1.43

3.9

UL 1007

22AWG

17/0.16

1.58

5.2

UL 1007

20AWG

26/0.16

1.76

7.2

UL 1007

18AWG

41/0.16

2.02

10.4

UL 1007

16AWG

65/0.16

2.38

15.6
